| Max. capacity |
500kgf, 1, 1.5, 2, 3, 5tf |
Rated output
Zoro balance |
1.7 ± 0.17mV/V
0 ± 0.016mV/V |
Combined error
Repeatability
Creep for 30min.
Temperature effect on
Zero Value
Output value |
0.14%R.O.
0.03%R.O.
0.03%R.O.
0.03%R.O./10℃
0.05%R.O./10℃
|
Excitation
Recommended
Maximum
Resistance
Input
Output
Insulation
|
10V
15V
760 ± 7Ω
700 ± 7Ω
＞2,000MΩ |
Compensated temperature range
Operating temperature range |
-10 to +40℃
-40 to +70℃ |
)
)
